TEHNIČKE SPECIFIKACIJE
DISPLAY CHARACTERISTICS
Design 3-side borderless
Diagonal 23.8", 60.5cm
Panel IPS Panel Technology LED, matte finish
Native resolution 1920 x 1080 @75Hz (2.1 megapixel Full HD)
Aspect ratio 16:9
Panel brightness 250 cd/m²
Static contrast 1000:1
Advanced contrast 80M:1
Response time (GTG) 4ms
Viewing zone horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support 16.7mln (sRGB: 99%; NTSC: 72%)
Horizontal Sync 30 - 85kHz
Viewable area W x H 527 x 296.5mm, 20.7 x 11.7"
Pixel pitch 0.275mm
Colour matte, black
INTERFACES / CONNECTORS / CONTROLS
Signal input HDMI x1
DisplayPort x1
USB-C x1 (Power delivery 65W)
Signal output DisplayPort x1 (Daisy Chain MST max. 1920 x 1080)
USB HUB x2 (v.3.0 (DC5V, 900mA))
USB-C DOCK x1 (Power delivery 65W, LAN, DP out, USB 3.0)
HDCP yes
Headphone connector yes
RJ45 (LAN) x1
FEATURES
Blue light reducer yes
Flicker free yes
OSD languages EN, DE, FR, ES, IT, RU, JP, CZ, NL, PL
Control buttons Power, Menu/ Select, Up/ Volume, Down/ ECO, Exit, Input
User controls picture adjust (brightness, contrast, Eco, blue light reducer, ACR, OD), colour settings (colour temp., user preset, i-Style colour), OSD (OSD H. position, OSD V. position, OSD rotate, OSD time), language, recall, miscellanous (sharp and soft, video mode adjust, opening logo, USB BC, MST, information), input select, audio settings (volume, mute)
Speakers 2 x 2W
Convenience Kensington-lock™ prepared, DDC2B
MECHANICAL
Display position adjustments height, swivel, tilt, pivot (rotation both sides)
Height adjustment 130mm
Rotation (PIVOT function) 90°
Swivel stand 90°; 45° left; 45° right
Tilt angle 22° up; 5° down
VESA mounting 100 x 100mm
Cable management system yes
Operation temperature range 5°C - 35°C
ACCESSORIES INCLUDED
Cables power, HDMI, USB-C
Other quick start guide, safety guide
POWER MANAGEMENT
Power supply unit internal
Power supply AC 100 - 240V, 50/60Hz
Power usage 19W typical, 0.5W stand by, 0.5W off mode
SUSTAINABILITY
Regulations TCO Certified, CE, TÜV-GS, EAC, VCCI-B, PSE, RoHS support, ErP, WEEE, REACH
Energy efficiency class (Regulation (EU) 2017/1369) F
REACH SVHC above 0.1%: Lead
DIMENSIONS / WEIGHT
Product dimensions W x H x D 539.5 x 366.5 (496.5) x 210mm
Box dimensions W x H x D 688 x 401 x 206mm
Weight (without box) 5.4kg
Weight (with box) 7.2kg
